Technical Description – SpyGlass SG50-F-IR3-H2 Triple IR Hydrogen Flame Detector
The SpyGlass SG50-F-IR3-H2 is the next generation of the IR3. It is being introduced to further enhance the protection and safety for these high risk and high value industries.
The SG50-F-IR3-H2 will detect hydrogen fires and explosions extremely fast, thus allowing preventative action to be initiated even more rapidly and minimizing the consequences!
A closer look
The unmatched detection times and distances are:
- Detection within 40 milliseconds of fireballs or explosions
- 5s for 32″ (0.8m) hydrogen fire at 0–66 ft. (0–20m)
- 4s for 32″ (0.8m) hydrogen fire at 66–100 ft. (20–30m)
- High immunity to false alarm
- Ultra-fast detection mode detection within 40 milliseconds for Hydrogen fireballs or explosions Hydrogen flame detection
- High sensitivity – up to 100 ft. (30m)
- Data/Event logger – alarms, faults and other relevant events are logged to non-volatile memory
- Built-in-Test (BIT) – Automatic and manual internal self-test of window cleanliness and the overall operation of the detector
- Window heater to avoid condensation and icing
The Specs at a Glance
| Technology | Triple IR Flame Detector for Energy Transition |
| Fire type | Hydrogen fires |
| Detection time and distance | 40ms for fast fire burst or explosion 1.5s for 32″ (0.8m) hydrogen fire at 0–66 ft. (0–20m) |
| Sensitivity Range | 5 ranges, Extreme, High, Medium, Low, Very Low |
| Field of view (IR detection) | 90° Horizontal, 75° Vertical |
| Output signal | |
| Standard | 3 wire and 4 wire (isolated) configurations (sink and source)4-20Ma or 0-22ma (configurable by the user)
Hart protocol 7th edition (option) |
| Relays | SPST volt-free contacts rated 2A at 30 VDC 3 relays: Alarm & Auxiliary – normally open; Fault – normally closed |
| Visual | Tri-colour LED (Green, Yellow, Red) |
| Modbus | RTU compatible on RS-485 |
| Electrical | |
| Power supply | 24 VDC nominal (18-32 VDC) |
| Power consumption | Standby: 120mA 180mA all systems in operation (including window heater) |
| Connection | 2x cable and conduit entries 3/4″ NPT(F) or M25x1.5 12-20AWG (2.5–0.35mm2) Shielded cable recommended |
| Environmental | |
| Temperature Range | Operating: -67°F to +185°F (-55°C to +85°C) Storage: -67°F to +185°F (-55°C to +85°C) |
| Option | Stainless steel weather cover, model FLS-WCO-S01 |
| Humidity | Up to 99% (RH), non-condensing |
| Ingress | IP66 & 68 (2m, 24hr); NEMA 4X & 6P |
| Mechanical | |
| Size | 5.51 x 3.54 x 3.54″ (140x90x90mm) |
| Weight | Detector (Stainless Steel 316): 6.6 lbs. (3.0 kg) Tilt mount (Stainless Steel 316): 3.3 lbs. (1.5 kg) |
